Woody’s Track Studding Template

Sale!
Woody's Track Studding Template

Woody’s Track Studding Template

Original price was: $9.98.Current price is: $7.57.

28 in stock

SKU: Woodys-252S-TEMP Categories: ,

Description

Woody’s Track Studding Template

Part Number: 252S-TEMP

  • For 14 Inch and 15 Inch wide Single-ply Tracks
  • Track length: 128 Inch
  • Track Pitch: 2.52
  • Center belt studding patterns only

Stud patterns are CAD-designed to maintain track balance. Follow the instructions to have the highest level of precision stud placement. Printed on laminated heavy card stock.

Studding Options:
102 studs with single support plates
153 studs with single support plates
102 studs with double support plates
153 studs with single/double support plates

Note: You MUST use Square Grand Digger or Double Grand Digger support plates. Round Grand Diggers are too large for the pitch.
